Coburg Tire Changer Machine
Product Details:
X
Product Description
Technical specification
AUTOMATIC TYRE CHANGER | CXR-503 | CXR-503+ |
Rim Clamping Outer | 11"-19" | 11"-19" |
Rim Clamping Inner | 12"-20" | 12"-24" |
Bead Breaker Force | 1800Kgs | 1800Kgs |
Max. Rotation Torque | 1100N-m | 1100N-m |
Max. Rim Diameter | 800 mm | 1000 mm |
Max. Rim Width | 320 mm | 320 mm |
Working Pressure | 6-8 bar(g) | 6-8 bar(g) |
Power Supply | 230 / 380V | 230 / 380V |
Motor Power | 1HP | 1HP |
Noise Level | <60dBA | <60dBA |
Nett Weight | 185Kgs | 185Kgs |
Dimensions | 1000x800x890 | 1000x800x890 |
