Car Washing Lift

Car Washing Lift

Product Details:

X

Product Description

Technical specification

CAR WASHING LIFT

CSPL-40

CSPL-40WP

CSPL-WPC

Lift Type

Chasis Lifting

Wheel Resting Platform

Wheel Resting Platform

Platform Material

MS Channel Frame

MS Gratings

Chequered Plate

Lifting Capacity

4 Ton

4 Ton

4 Ton

No. of Plungers

1 No.

1 No.

1 No.

Lifting Height

1500mm

1500mm

1500mm

Oil Capacity

160 Litres

160 Litres

160 Litres

Oil Tank Capacity

160 Litres

160 Litres

160 Litres

Plunger

18-20 Microns

18-20 Microns

18-20 Microns

Cylinder Dia

270 mm

270 mm

270 mm

Platform Size

700 X 3600 mm

2000 X 3600 mm

2000 X 4500 mm

Air Pressure

9-12 Kg/cm²

9-12 Kg/cm131

9-12 Kg/cm132

Control Valve

1 No.

1 No.

1 No.

Rails

4 Nos.

4 Nos.

4 Nos.
